WORKING ENVIRONMENT
Working Environment Temperature : -25°C ~ +70°C
Storage Temperature : -40°C ~ +70°C
Class Of Pollution : 3
Protection Grade : IP40/IP65/IP66
Limit Height : ≤2000M
Standard : EN 60947-1,GB14048.5
MAIN TECHNICAL DATA
Rated Insulation Voltage : 600V
Rated Thermal Current : 10A
Switch Rating: AC-15 Ue : 380V/250V, Ie=4.5A
DC-13 Ue : 220V/110V, Ie=0.6A
Contact Resistance : ≤50 mA
Recommended Torque : 0.9 Nm
Mechanical Life Of Push Button : ≥300×104 times
Electrical Life : ≥30X104 times
